ECDIS Quick Reference Guide for Mariners: JRC JAN-7201/JAN-9201

Number of Pages:
Published Date:
March 2022
Book Height:
297 mm
Book Width:
210 mm
0.6 kg
Current Stock:
Adding to cart… The item has been added

This title has already been added to your basket for browser access. If you require access for more than one user, please contact us.

This title is part of the ECDIS Quick Reference Guide for Mariners series. Designed for mariners at any stage of their maritime training and careers, each Guide offers a quick reference for a specific ECDIS manufacturer. This Guide is for JRC (JAN-7201/JAN-9201) Electronic Chart Display and Information Systems.

The Guide is presented in tabular format with graphic reproductions of ECDIS screenshots and lined pages at the end for important note taking. It includes information on:

  • Key ECDIS menu functions
  • Main display
  • Navigation tools
  • Chart display settings
  • Route planning
  • Route monitoring
  • System settings.

Type Specific and Familiarisation Training

All ECDIS operators, having completed generic training, are required to undertake type specific ECDIS training in order to be familiar with the equipment in use on their vessel. This is in line with ISM and flag State legislation (flag State dependent).

In addition to type specific training, onboard familiarisation training is considered best practice. Each manufacturer’s software version and installation may vary from the type that the ECDIS operator has been trained on. Therefore, a Familiarisation Checklist can assist ECDIS operators in gaining and refreshing knowledge of ship specific installations.

Small variations in menu structures or terminology may be experienced due to the larger number of software patches, updates and optional extras available for each manufacturer. However, all efforts have been made to give a reflection of the manufacturers’ latest version of software based on the average optional extras that ships purchase. Should you be aware of any minor updates that need to be added, please email:
