Guidance Manual for Tanker Structures - Consolidated Edition 2027

This consolidated edition has been updated to reflect the completed transition to double hull oil tankers, with guidance aligned to 'IACS Unified Requirements (UR) Survey and Certification: Z10.4 Hull Surveys of Double Hull Oil Tankers (Rev.18 Feb 2023)' and Chapter 15 of the 'Code of Safe Working Practices for Merchant Seafarers (COSWP) - 2026 Edition' on safe enclosed space entry, which is now included in the manual.

The guidance manual supplies comprehensive information on IACS survey requirements for Special, Annual and Intermediate Surveys, survey preparation and reporting, thickness measurements, structural defects, corrosion, maintenance and repairs and required survey documentation. Practical guidance from the Tanker Structure Co-operative Forum to support the assessment and monitoring of in-service tanker structures is also provided.

An ideal resource for those who require all of the necessary information to assess and monitor the condition of in-service ballast tanks, cargo tanks and other tanker structures.

This consolidated edition combines in one guidance manual the various sources of information necessary for assessing the condition of the ballast tanks, cargo tanks and structure of tankers in service. While the original manual mainly addressed the conventional single hull tanker, this revision includes IACS Unified Requirements (UR) Survey and Certification: Z10.4 Hull Surveys of Double Hull Oil Tankers (Rev.18 Feb 2023), where changes introduced in Rev.18 are to be uniformly applied by IACS Societies for surveys commenced on or after 1 July 2024.

This Guidance Manual has been updated to provide a comprehensive overview of:
- IACS requirements for Special, Annual and Intermediate Surveys
- survey preparation, including a review of requirements, safety aspects, equipment and details of carrying out and reporting different types of surveys
- thickness measurements
- technical background and awareness of structural defects in terms of the effects on local strength or overall structural integrity
- basic maintenance and repair guidelines are provided along with sketches of experienced structural failures and proposed repairs
- documentation required for survey, including supporting documents
- the guidance of the Tanker Structure Co-operative Forum (see Appendix I for further details of the Forum) in areas of corrosion, defects and repairs, ultrasonic gauging and the strength of corroded structural items, as well as corrosion and maintenance evaluation of tanker structures.
