Anchor Handling (Oilfield Seamanship Series Volume 3)

Number of Pages:
Published Date:
May 1994
Book Height:
300 mm
Book Width:
210 mm
1.2 kg
Current Stock:
Adding to cart… The item has been added

This title has already been added to your basket for browser access. If you require access for more than one user, please contact us.

This book will benefit Masters, officers and other personnel operating anchor handling vessels. It describes the most common work boat operations, which differ to those of the barge or vessel being worked. A number of specialist mooring operations are also described, again from the boat’s viewpoint. Previously published by Clarkson Research Services Ltd.

This volume of the Oilfield Seamanship Series provides practical guidance on all aspects of anchor handling, such as anchor retrieval, rigging for anchor handling and recovery gear for fishing and grappling operations. The book is supported by extensive diagrams, illustrating sequences such as breaking out anchors and the stowage of chain on deck, as well as equipment design.
